ISD4004 Series
22 Voice Solutions in Silicon ™
1. Double bond recommended.
Table 16: ISD4004 Series Device Pin/Pad Designations,
with Respect to Die Center (µm)
Pin Pin Name X Axis Y Axis
V
SSA
V
SS
Analog Power Supply –1898.1 –4622.4
V
SSA
V
SS
Analog Power Supply –1599.9 –4622.4
AUD OUT Audio Output 281.9 –4622.4
AM CAP AutoMute 577.3 –4622.4
ANA IN – Inverting Analog Input 1449.4 –4622.4
ANA IN + Noninverting Analog Input 1603.5 –4622.4
V
CCA
(1)
V
CC
Analog Power Supply 1898.7 –4622.4
V
SSA
V
SS
Analog Power Supply 1885.2 –4622.4
RAC Row Address Clock 1483.8 4623.7
INT Interrupt 794.8 4623.7
XCLK External Clock Input 564.8 4623.7
V
CCD2
V
CC
Digital Power Supply 387.9 4623.7
V
CCD1
V
CC
Digital Power Supply 169.5 4623.7
SCLK Slave Clock –14.7 4623.7
SS Slave Select –198.1 4623.7
MOSI Master Out Slave In –1063.7 4623.7
MISO Master In Slave Out –1325.6 4623.7
V
SSD1
V
SS
Digital Power Supply –1655.3 4623.7
V
SSD2
V
SS
Digital Power Supply –1836.9 4623.7
