1. Typical values: T
A
= 25°C and 3.0 V.
2. All min/max limits are guaranteed by ISD via electrical testing or characterization. Not all specifications are 100 percent
tested.
3. Low-frequency cut off depends upon the value of external capacitors (see Pin Descriptions).
4. Single-ended input mode. In the differential input mode, V
IN
maximum for ANA IN+ and ANA IN– is 16mVp-p.
5. Sampling Frequency can vary as much as ±2.25 percent over the commercial temperature, and voltage ranges,
and –6/+4 percent over the extended temperature, industrial temperature and voltage ranges. For greater
stability, an external clock can be utilized (see Pin Descriptions).
6. Playback and Record Duration can vary as much as ±2.25 percent over the commercial temperature and voltage
ranges, and –6/+4 percent over the extended temperature, industrial temperature and voltage ranges. For
greater stability, an external clock can be utilized (see Pin Descriptions).
7. Filter specification applies to the antialiasing filter and the smoothing filter. Therefore, from input to output, expect a
6dB drop by nature of passing through both filters.
8. The typical output voltage will be approximately 570mVp-p with V
IN
at 32mVp-p.
9. For optimal signal quality, this maximum limit is recommended.
10. When a record command is sent, T
RAC
= T
RAC
+ T
RACLO
on the first row addressed.
T
PLAY
Playback Duration ISD4004-08M
ISD4004-10M
ISD4004-12M
ISD4004-16M
8
10
12
16
min
min
min
min
(6)
(6)
(6)
(6)
T
PUD
Power-Up Delay ISD4004-08M
ISD4004-10M
ISD4004-12M
ISD4004-16M
25
31.25
37.5
50
msec
msec
msec
msec
T
STOP
or
T
PAUSE
Stop or Pause in
Record or Play
ISD4004-08M
ISD4004-10M
ISD4004-12M
ISD4004-16M
50
62.5
75
100
msec
msec
msec
msec
T
RAC
RAC Clock Period ISD4004-08M
ISD4004-10M
ISD4004-12M
ISD4004-16M
200
250
300
400
msec
msec
msec
msec
(10)
(10)
(10)
(10)
T
RACLO
RAC Clock Low
Time
ISD4004-08M
ISD4004-10M
ISD4004-12M
ISD4004-16M
25
31.25
37.5
50
msec
msec
msec
msec
T
RACM
RAC Clock Period
in Message
Cueing Mode
ISD4004-08M
ISD4004-10M
ISD4004-12M
ISD4004-16M
125
156.3
187.5
250
µsec
µsec
µsec
µsec
T
RACML
RAC Clock Low
Time in Message
Cueing Mode
ISD4004-08M
ISD4004-10M
ISD4004-12M
ISD4004-16M
15.63
19.53
23.44
31.25
µsec
µsec
µsec
µsec
THD Total Harmonic Distortion 1 2 % @ 1 KHz
V
IN
ANA IN Input Voltage 32 mV Peak-to-Peak
(4) (8) (9)
Table 7: AC Parameters (Packaged Parts)
Symbol Characteristic Min (2) Typ (1) Max (2) Units Conditions
