Application circuit
1) Application circuit as ordinal supply detection reset is shown below.
Output type of BD52XXG/FVE series (Open drain type) and BD53XXG/FVE series (CMOS type) is different.
An example of usage is shown below.
1 When the power supply of microcontroller (V
DD2
) and power supply for the reset detection (V
DD1
) is different.
Provide RL for the output of a product with open drain output (BD52XXG/FVE series) on the V
DD2
side,
as shown in Fig.10.
2 When the power supply of microcontroller and that of reset is same (V
DD1
).
A product with CMOS output (BD53XXG/FVE series) can be used as shown in Fig.11. Or if RL is provided
with open drain output (BD52XXG/FVE series) on the V
DD1
side, it can be used.
Fig.10 Open collector output type
Fig.11 CMOS output type
Fig.14 Delay time I/O condition
Fig.12
Fig.13
When the capacitor C
L
for noise filtering is connected to V
OUT
pin (reset signal input pin of microcontroller),
make a setting in consideration of the wave rounding of the rise and fall of V
OUT
pin.
