Cmos voltage detector ic with delay time circuit, Bd52xxg/fve bd53xxg/fve, Part no. : b d 5 x x x x

Features
Applications
CMOS VOLTAGE DETECTOR IC
with Delay Time Circuit
BD52XXG/FVE
BD53XXG/FVE
Selection guide
ROHM's BD52XXG/FVE and BD53XXG/FVE are series of high-accuracy, low-power VOLTAGE DETECTOR ICs
with a CMOS process. These series can set delay time by external capacitor. For flexible choice according to the
application, BD52XXG/FVE series with N channel open drain output and BD53XXG/FVE series with CMOS output
are available in 38 voltage types which detection voltage is from 2.3V to 6.0V in steps of 0.1V in different packages,
totaling 152 models.
1) Detection voltage: 0.1V step line-up 2.3 to 6.0V (Typ.)
2) High-accuracy detection voltage: ±1.5% guranteed (Ability ±1%)
3) Ultra low current consumption: 0.85µA typ. (Output is High.)
4) Delay time can be set by external capacitor.
5) Nch open drain output (BD52XXG/FVE series), CMOS output (BD53XXG/FVE series)
6) Small package of VSOF5
(EMP5)
(BD52XXFVE/BD53XXFVE), and SSOP5
(SMP5C2)
(BD52XXG/BD53XXG)
Every kind of appliances with microcontroller and logic circuit
For BD5XXXX series, detection voltage, output circuit types (Refer to the block diagram at P3),and package
(Refer to the block diagram at P14) can be selected for your own application.Part number of devices for each
specification is shown below.
Part No. : B D 5 X X X X
Part No.
Specification
Contents
Output circuit types
Package
Detection voltage
2 : Open drain output
3 : CMOS output
Ex. : V
DET
: described in each 0.1V step
for 2.3V to 6.0V range (29 means 2.9V)
G : SSOP5
(SMP5C2)
FVE : VSOF5
(EMP5)
1
2
3
1
2
3
1/15
Voltage detectors
BD52XXG/FVE
BD53XXG/FVE
Rev.A
