DS8024
Smart Card Interface
6 _______________________________________________________________________________________
Pin Description
PIN NAME FUNCTION
1, 2
CLKDIV1,
CLKDIV2
Clock Divider. Determines the divided-down input clock frequency (presented at XTAL1 or from a
crystal at XTAL1 and XTAL2) on the CLK output pin. Dividers of 1, 2, 4, and 8 are available.
3 5V/3V
5V/3V Selection Pin. Allows selection of 5V or 3V for communication with an IC card. Logic-high selects
5V operation; logic-low selects 3V operation. See Table 3 for a complete description of choosing card
voltages.
4 PGND Analog Ground
5, 7 CP2, CP1
Step-Up Converter Contact. Charge-pump capacitor. Connect a 100nF capacitor (ESR < 100m )
between CP1 and CP2.
6 V DDA Charge-Pump Supply. Must be equal to or higher than V DD . Connect a supply of at least 3.3V.
8 V UP Charge-Pump Output. Connect a 100nF capacitor (ESR < 100m ) between V UP and GND.
9 PRES
Card Presence Indicator. Active-low card presence inputs. When the presence indicator becomes
active, a debounce timeout begins. After 8ms (typ) the OFF signal becomes active.
10 PRES
Card Presence Indicator. Active-high card presence inputs. When the presence indicator becomes
active, a debounce timeout begins. After 8ms (typ) the OFF signal becomes active.
11 I/O Smart Card Data-Line Output. Card data communication line, contact C7.
12, 13
AUX2,
AUX1
Smart Card Auxiliary Line (C4, C8) Output. Data line connected to card reader contacts C4 (AUX1) and
C8 (AUX2).
14 CGND Smart Card Ground
15 CLK Smart Card Clock. Card clock, contact C3.
16 RST Smart Card Reset. Card reset output from contact C2.
17 V CC
Smart Card Supply Voltage. Decouple to CGND (card ground) with 2 x 100nF or 100 + 220nF
capacitors (ESR < 100m
).
18 N.C. No Connection. Unused on the DS8024.
19 CMDVCC Activation Sequence Initiate. Active-low input from host.
20 RSTIN Card Reset Input. Reset input from the host.
21 V DD Supply Voltage
22 GND Digital Ground
23 OFF Status Output. Active-low interrupt output to the host. Use a 20k integrated pullup resistor to V
DD .
24, 25
XTAL1,
XTAL2
Crystal/Clock Input. Connect an input from an external clock to XTAL1 or connect a crystal across
XTAL1 and XTAL2. For the low idle-mode current variant, an external clock must be driven on XTAL1.
26 I/OIN I/O Input. Host-to-interface chip data I/O line.
27, 28
AUX1IN,
AUX2IN
C4/C8 Input. Host-to-interface I/O line for auxiliary connections to C4 and C8.
