DS1558
11 of 18
ABSOLUTE MAXIMUM RATINGS*
Voltage Range on Any Pin Relative to Ground -0.3V to +6.0V
Storage Temperature Range -55 °C to +125°C
Soldering Temperature Range See IPC/JEDEC J-STD-020A
*This is a stress rating only and functional operation of the device at these or any other conditions beyond those indicated in the operation
sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods of time can affect reliability.
RECOMMENDED DC OPERATING CONDITIONS
(V
CC
= 3.3V ±10% or 5V ±10%, T
A
= -40°C to +85°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Logic 1 Voltage (All Inputs)
V
CC
= +5V ±10% V
IH
2.2 V
CC
+ 0.3V V 1
V
CC
= +3.3V ±10% V
IH
2.0 V
CC
+ 0.3V V 1
Logic 0 Voltage (All Inputs)
V
CC
= +5V ±10% V
IL
-0.3 +0.8 1
V
CC
= +3.3V ±10% V
IL
-0.3 +0.6 1
Battery Voltage V
BAT
2.5 3.3 3.7 V
