12
4866A–GPS–08/05
ATR0601 [Preliminary]
Table 9-3. Specification of GPS TCXOs Appropriate for the Application Example Shown in
Figure 9-3 on page 10
Parameter Comment Min. Typ. Max. Units
Frequency Characteristics
Nominal Frequency
Nominal frequency referenced to
25°C
23.104 MHz
Frequency deviation Over operating temperature range 2.0 ±ppm
Temperature range Operating temperature range –40.0 +85.0 °C
Electrical
Output waveform DC coupled clipped sinewave
Output voltage
(peak-to-peak)
At minimum supply voltage 0.8 V
Output load capacitance Tolerable load capacitance 10 pF
Table 9-4. Specification of an external reference signal for the application example shown in
Figure 9-4 on page 10
Parameter Comment Min. Typ. Max. Units
Signal Characteristics
Nominal Frequency 23.104 MHz
Waveform Sinewave or clipped sinewave
Amplitude Voltage peak-to-peak 0.6 0.8 1.0 V
