DS3690
3.3V 26-Channel, Three-Stateable
Transmission Gate
_______________________________________________________________________________________ 5
Pin Description
PIN NAME FUNCTION
1 CH01A Channel 1 Terminal A
2 CH02A Channel 2 Terminal A
3 CH03A Channel 3 Terminal A
4 CH04A Channel 4 Terminal A
5 CH05A Channel 5 Terminal A
6 CH06A Channel 6 Terminal A
7 CH07A Channel 7 Terminal A
8 CH08A Channel 8 Terminal A
9 CH09A Channel 9 Terminal A
10 CH10A Channel 10 Terminal A
11 CH11A Channel 11 Terminal A
12 CH12A Channel 12 Terminal A
13 CH13A Channel 13 Terminal A
14 CH14A Channel 14 Terminal A
15 CH15A Channel 15 Terminal A
16 CH16A Channel 16 Terminal A
17 CH17A Channel 17 Terminal A
18 CH18A Channel 18 Terminal A
19 CH19A Channel 19 Terminal A
20 CH20A Channel 20 Terminal A
21 CH21A Channel 21 Terminal A
22 CH22A Channel 22 Terminal A
23 CH23A Channel 23 Terminal A
24 V CC Supply Voltage
25, 53 GND Ground
26 CH23B Channel 23 Terminal B
27 CH22B Channel 22 Terminal B
28 CH21B Channel 21 Terminal B
29 CH20B Channel 20 Terminal B
PIN NAME FUNCTION
30 CH19B Channel 19 Terminal B
31 CH18B Channel 18 Terminal B
32 CH17B Channel 17 Terminal B
33 CH16B Channel 16 Terminal B
34 CH15B Channel 15 Terminal B
35 CH14B Channel 14 Terminal B
36 CH13B Channel 13 Terminal B
37 CH12B Channel 12 Terminal B
38 CH11B Channel 11 Terminal B
39 CH10B Channel 10 Terminal B
40 CH09B Channel 9 Terminal B
41 CH08B Channel 8 Terminal B
42 CH07B Channel 7 Terminal B
43 CH06B Channel 6 Terminal B
44 CH05B Channel 5 Terminal B
45 CH04B Channel 4 Terminal B
46 CH03B Channel 3 Terminal B
47 CH02B Channel 2 Terminal B
48 CH01B Channel 1 Terminal B
49 CH24B Channel 24 Terminal B
50 CH25B Channel 25 Terminal B
51 CH26B Channel 26 Terminal B
52 CE Chip-Enable Input (Active Low)
54 CH26A Channel 26 Terminal A
55 CH25A Channel 25 Terminal A
56 CH24A Channel 24 Terminal A
— EP
Exposed Paddle. Must be
connected to ground.
