DS3690
3.3V 26-Channel, Three-Stateable
Transmission Gate
4 _______________________________________________________________________________________
Typical Operating Characteristics
(V CC = 3.3V, T A = +25°C, unless otherwise noted.)
POWER-SUPPLY CURRENT
vs. INPUT VOLTAGE
DS3690 toc01
INPUT VOLTAGE (V)
SUPPLY CURRENT (A)
3.2 2.9 2.3 2.0 2.6
1.E-09
1.E-08
1.E-07
1.E-06
1.E-05
1.E-04
1.E-03
1.E-02
1.E-10
CE = CH1A–CH26A,
CH1B–CH26B = FLOAT
T A = +85 °C T A = +85 °C
T A = +25 °C T A = +25 °C
T A = -55 °C T A = -55 °C
CHANNEL ON-RESISTANCE CHANGE
vs. INPUT VOLTAGE
DS3690 toc02
INPUT VOLTAGE (V)
DELTA RESISTANCE (
Ω
)
2.6 2.0 1.3 0.7
5
10
15
20
25
0
0.0 3.3
I OUT = -0.1mA, CH1
OUTPUT-VOLTAGE HIGH
vs. OUTPUT CURRENT
DS3690 toc03
OUTPUT CURRENT (mA)
OUTPUT VOLTAGE (V)
-1 -2 -3 -4
2.7
2.8
2.9
3.0
3.1
3.2
2.6
-5 0
V IN = +3.0V, CH1A–CH1B
OUTPUT-VOLTAGE LOW
vs. OUTPUT CURRENT
DS3690 toc04
OUTPUT CURRENT (mA)
OUTPUTVOLTAGE (V)
4 3 2 1
0.1
0.2
0.3
0.4
0.5
0.6
0.0
0 5
V IN = +0.3V, CH1A–CH1B
