DS3690
3.3V 26-Channel, Three-Stateable
Transmission Gate
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
RECOMMENDED OPERATING CONDITIONS
(T
A
= -55°C to +85°C)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltage Range on Any Pin Relative to Ground......-0.5V to +6.0V
Operating Temperature Range ...........................-55°C to +85°C
Storage Temperature Range .............................-55°C to +125°C
Soldering Temperature...................Refer to IPC/JEDEC J-STD-020
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
V
CC
(Note 1)
2.7
3.3
3.6
V
Input Logic 1
V
IH
(Note 1)
0.7 x
V
CC
V
CC
+
0.3
V
Input Logic 0
V
IL
(Note 1)
-0.3
0.3 x
V
CC
V
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +2.7V to +3.6V, T
A
= -55°C to +85°C, unless otherwise noted.)
PARAMETER SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Standby Current
I
CC
CE = CH1 CH26 = V
CC
, I
OUT
= 0mA
1
μA
Input Leakage Current (CE) I
I
V
IN
= 0V to V
CC
, T
A
= +25°C
-0.1
+0.1
μA
I/O Leakage Current
I
IO
CE = V
IH
-1.0
+1.0
μA
AC ELECTRICAL CHARACTERISTICS
(V
CC
= +2.7V to +3.6V, T
A
= -55°C to +85°C, unless otherwise noted.)
PARAMETER SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Propagation Delay
(A to B or B to A)
t
PD
CE = V
IL
(Note 2)
10
ns
Chip Enable to Output Valid
t
CEV
(Notes 2, 3)
20
ns
Chip Enable to Output Deselect
t
CEZ
(Notes 2, 3)
20
ns
Input to CE Setup Time
t
IS
(Note
4)
0
ns
Skew Between Channels
t
S
(Notes 5, 6)
1
ns
Input Pulse Levels:
V
IL
= 0.0V, V
IH
= 2.7V
Input Pulse Rise and Fall Times:
5ns
Input and Output Timing Reference Level:
V
CC
/2
Output Load:
C
L
(100pF)
AC TEST CONDITIONS
