LEA-5H, LEA-5S, LEA-5A - Data Sheet Preliminary u-blox proprietary
GPS.G5-MS5-07026-P4 Page 13
your position is our focus
7 Default Settings
Interface Settings
Serial Port 1
Output 9600 Baud, 8 bits, no parity bit, 1 stop bit
Configured to transmit both NMEA and UBX protocols, but only
following NMEA and no UBX messages have been activated at start-up:
GGA, GLL, GSA, GSV, RMC, VTG, TXT
USB Output Configured to transmit both NMEA and UBX protocols, but only
following NMEA and no UBX messages have been activated at start-up:
GGA, GLL, GSA, GSV, RMC, VTG, TXT
USB Power Mode: Bus-Powered
Serial Port 1 Input 9600 Baud, 8 bits, no parity bit, 1 stop bit
Automatically accepts following protocols without need of explicit
configuration:
UBX, NMEA
The GPS receiver supports interleaved UBX and NMEA messages.
USB Input Automatically accepts following protocols without need of explicit
configuration:
UBX, NMEA
The GPS receiver supports interleaved UBX and NMEA messages.
USB Power Mode: Bus-Powered
TIMEPULSE
(1Hz Nav)
1 pulse per second, synchronized at rising edge, pulse length 100ms
Table 13: Available Protocols.
Please refer to the LEA-5 Hardware Integration Manual [1] for information about further settings.
