LEA-5H, LEA-5S, LEA-5A - Data Sheet Preliminary u-blox proprietary
GPS.G5-MS5-07026-P4 Page 10
your position is our focus
4 Electrical Specifications
4.1 Absolute Maximum Ratings
Parameter Symbol Min Max Units
Power supply voltage (VCC) Vcc -0.5 3.6 V
Backup battery voltage (V_BCKP) Vbckp -0.5 4.8 V
Vin -0.5 Vcc +0.5 V Input pin voltage
Vin_usb -0.5 Vddusb +0.5 V
VCC_RF output current Iccrf 100 mA
Antenna bias voltage Vant 6 V
Antenna bias current 5 Iant 100 mA
Storage temperature Tstg -40 85 °C
Table 9: Absolute Maximum Ratings
Stressing the device beyond the “Absolute Maximum Ratings” may cause permanent damage.
These are stress ratings only. The product is not protected against overvoltage or reversed
voltages. If necessary, voltage spikes exceeding the power supply voltage specification, given in
table above, must be limited to values within the specified boundaries by using appropriate
protection diodes.
5 Applied via V_ANT
