LEA-5H, LEA-5S, LEA-5A - Data Sheet Preliminary u-blox proprietary
GPS.G5-MS5-07026-P4 Page 12
your position is our focus
5 Reliability Tests
Tests for product family qualifications:
Test Standard
Visual inspection IPC-A-610 “Acceptability of electronic
assemblies”
I.T.R.I. Publication No. 700
IPC-SM-840B Class 2.
Thermal shock -40°C...+125°C, 100 cycles IEC 68-2-14
Function at
various
temperatures -40°C/2 hours; RT/2 hours;
+85°C/2 hours; function tests at stable
temperature IEC 68-2-1 and IEC 68-2-2
Lifespan test +85°C/1000 hours, in function IEC 68-2-2
Damp heat, cyclic +25°C...+55°C; >90% Rh IEC 68-2-30
Vibration 10-500 Hz; 2 hours/axis; 5g IEC 68-2-6
Shock 30g/11ms (halfsine); 3 Shock/axis; no
function IEC 68-2-27
Metallographic
investigations IPC-QE-650
Table 11: Reliability Tests
This specification is preliminary and subject to confirmation.
6 Design-In
In order to obtain the necessary information to conduct a proper design-in, u-blox strongly recommends
consulting the LEA-5 Hardware Integration Manual [1].
