DS1822-PAR
16 of 19
DS1822-PAR OPERATION EXAMPLE 1
In this example there are multiple DS1822-PARs on the bus. The bus master initiates a temperature
conversion in a specific DS1822-PAR and then reads its scratchpad and recalculates the CRC to verify
the data.
MASTER MODE DATA (LSB FIRST) COMMENTS
TX Reset Master issues reset pulse.
RX Presence DS1822-PARs respond with presence pulse.
TX 55h Master issues Match ROM command.
TX 64-bit ROM code Master sends DS1822-PAR ROM code.
TX 44h Master issues Convert T command.
TX DQ line held high by
strong pullup
Master applies strong pullup to DQ for the duration of the
conversion (t
conv
).
TX Reset Master issues reset pulse.
RX Presence DS1822-PARs respond with presence pulse.
TX 55h Master issues Match ROM command.
TX 64-bit ROM code Master sends DS1822-PAR ROM code.
TX BEh Master issues Read Scratchpad command.
RX 9 data bytes Master reads entire scratchpad including CRC. The master
then recalculates the CRC of the first eight data bytes from the
scratchpad and compares the calculated CRC with the read
CRC (byte 9). If they match, the master continues; if not, the
read operation is repeated.
DS1822-PAR OPERATION EXAMPLE 2
In this example there is only one DS1822-PAR on the bus. The master writes to the T
H
, T
L
, and
configuration registers in the DS1822-PAR scratchpad and then reads the scratchpad and recalculates the
CRC to verify the data. The master then copies the scratchpad contents to EEPROM.
MASTER MODE DATA (LSB FIRST) COMMENTS
TX Reset Master issues reset pulse.
RX Presence DS1822-PAR responds with presence pulse.
TX CCh Master issues Skip ROM command.
TX 4Eh Master issues Write Scratchpad command.
TX 3 data bytes Master sends three data bytes to scratchpad (T
H
, T
L
, and config).
TX Reset Master issues reset pulse.
RX Presence DS1822-PAR responds with presence pulse.
TX CCh Master issues Skip ROM command.
TX BEh Master issues Read Scratchpad command.
RX 9 data bytes Master reads entire scratchpad including CRC. The master then
recalculates the CRC of the first eight data bytes from the
scratchpad and compares the calculated CRC with the read CRC
(byte 9). If they match, the master continues; if not, the read
operation is repeated.
TX Reset Master issues reset pulse.
RX Presence DS1822-PAR responds with presence pulse.
TX CCh Master issues Skip ROM command.
TX 48h Master issues Copy Scratchpad command.
TX DQ line held high by
strong pullup
Master applies strong pullup to DQ for at least 10 ms while copy
operation is in progress.
