ATF22V10C(Q)Z
11
Using “C” Product for Industrial
To use commercial product for Industrial temperature ranges, down-grade one speed grade from the “I” to the “C” device
(7 ns “C” = 10 ns “I”) and de-rate power by 30%.
ATF22V10CZ/CQZ Ordering Information
t
PD
(ns)
t
S
(ns)
t
CO
(ns) Ordering Code Package Operation Range
12 10 8 ATF22V10CZ-12JC
ATF22V10CZ-12PC
ATF22V10CZ-12SC
ATF22V10CZ-12XC 28J
24P3
24S
24X Commercial
(0 °C to 70°C)
15 4.5 8 ATF22V10CZ-15JC
ATF22V10CZ-15PC
ATF22V10CZ-15SC
ATF22V10CZ-15XC 28J
24P3
24S
24X Commercial
(0 °C to 70°C)
ATF22V10CZ-15JI
ATF22V10CZ-15PI
ATF22V10CZ-15SI
ATF22V10CZ-15XI 28J
24P3
24S
24X Industrial
(-40 °C to +85°C)
20 14 12 ATF22V10CQZ-20JC
ATF22V10CQZ-20PC
ATF22V10CQZ-20SC
ATF22V10CQZ-20XC 28J
24P3
24S
24X Commercial
(0
°C to 70°C)
ATF22V10CQZ-20JI
ATF22V10CQZ-20PI
ATF22V10CQZ-20SI
ATF22V10CQZ-20XI 28J
24P3
24S
24X Industrial
(-40
°C to +85°C)
Package Type
28J 28-lead, Plastic J-leaded Chip Carrier (PLCC)
24P3 24-pin, 0.300", Plastic Dual Inline Package (PDIP)
24S 24-lead, 0.300" Wide, Plastic Gull-Wing Small Outline (SOIC)
24X 24-lead, 4.4 mm Wide, Plastic Thin Shrink Small Outline (TSSOP)
