DS8313/DS8314
Smart Card Interface
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
RECOMMENDED DC OPERATING CONDITIONS
(V
DD
= +3.3V, V
DDA
= +5.0V, T
A
= +25°C, unless otherwise noted. All specifications apply to both the DS8313 and DS8314, unless
otherwise noted in the CONDITIONS column.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltage Range on V
DD
Relative to GND ...............-0.5V to +6.5V
Voltage Range on V
DDA
Relative to GND .............-0.5V to +6.5V
Voltage Range on All Other Pins
Relative to GND......................................-0.5V to (V
DD
+ 0.5V)
Maximum Junction Temperature .....................................+125°C
Maximum Power Dissipation (T
A
= -25°C to +85°C) .......700mW
Storage Temperature Range .............................-55°C to +150°C
Soldering Temperature.........Refer to the IPC/JEDEC J-STD-020
Specification.
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
POWER SUPPLY
Digital Supply Voltage
V
DD
2.7 6.0 V
Card Voltage-Generator Supply Voltage
V
DDA
DS8313,
DS8314
4.75 6.0 V
V
TH2
Threshold
voltage
(falling)
2.35
2.45
2.65 V
Reset Voltage Thresholds
V
HYS2
Hysteresis
50 100 150 mV
CURRENT CONSUMPTION
Active V
DD
Current 5V Cards
(Including 80mA Draw from 5V Card)
I
DD_50V
I
CC
= 80mA, f
XTAL
= 20MHz,
f
CLK
= 10MHz, V
DDA
= 5.0V
80.75
85 mA
Active V
DD
Current 5V Cards (Current
Consumed by DS8313/DS8314 Only)
I
DD_IC
I
CC
= 80mA, f
XTAL
= 20MHz,
f
CLK
= 10MHz, V
DDA
= 5.0V (Note 2)
0.75 5 mA
Active V
DD
Current 3V Cards
(Including 65mA Draw from 3V Card)
I
DD_30V
I
CC
= 65mA, f
XTAL
= 20MHz,
f
CLK
= 10MHz, V
DDA
= 5.0V
65.75
70 mA
Active V
DD
Current 3V Cards (Current
Consumed by DS8313/DS8314 Only)
I
DD_IC
I
CC
= 65mA, f
XTAL
= 20MHz,
f
CLK
= 10MHz, V
DDA
= 5.0V (Note 2)
0.75 5 mA
Active V
DD
Current 1.8V Cards
(Including 30mA Draw from 1.8V Card)
I
DD_18V
I
CC
= 30mA, f
XTAL
= 20MHz,
f
CLK
= 10MHz, V
DDA
= 5.0V
30.75
40 mA
Active V
DD
Current 1.8V Cards (Current
Consumed by DS8313/DS8314 Only)
I
DD_IC
I
CC
= 30mA, f
XTAL
= 20MHz,
f
CLK
= 10MHz, V
DDA
= 5.0V (Note 2)
0.75 5 mA
Inactive-Mode Current
I
DD
Card inactive, active-high PRES,
DS8313/DS8314 not in stop mode
50
40 μA
Stop-Mode Current
I
DD_STOP
DS8313/DS8314 in ultra-low-power
stop mode (CMDVCC, 5V/3V, and
1_8V set to logic 1) (Note 3)
10 μA
