ATF1500A(L)
12
NORMALIZED SUPPLY CURRENT
vs. INPUT FREQUENCY
ATF1500A (V
cc
= 5V, TA = 25˚C)
I
CC
NORMALIZED SUPPLY CURRENT
vs. SUPPLY VOLTAGE
ATF1500 (TA = 25˚C)
I
CC
I
OH
OUTPUT SOURCE CURRENT
vs. SUPPLY VOLTAGE (V
OH
= 2.4V, TA = 25˚C)
I
OH
mA
OUTPUT SOURCE CURRENT
vs. OUTPUT VOLTAGE (V
OH
= 2.4V, TA = 25˚C)
SUPPLY CURRENT
vs. FREQUENCY
ATF1500AL (V
CC
= 5V, TA = 25˚C)
I
CC
mA
NORMALIZED SUPPLY CURRENT
vs. AMBIENT TEMPERATURE
ATF1500 (V
CC
= 5V)
I
CC
mA
OUTPUT SINK SURRENT
vs. SUPPLY VOLTAGE (TA = 25˚C, V
OL
= 0.45V)
I
OL
mA
OUTPUT SOURCE CURRENT
vs. OUTPUT VOLTAGE (V
CC
= 5V, TA = 25˚C)
I
OH
mA
