DS2406
28 of 31
ABSOLUTE MAXIMUM RATINGS*
Voltage on DATA or PIO-A to Ground -0.5V to +13.0V
Voltage on V
CC
or PIO-B to Ground -0.5V to +6.5V
Operating Temperature Range -40°C to +85°C
Storage Temperature Range -55°C to +125°C
Soldering Temperature See J-STD-020A Specifications
* This is a stress rating only and functional operation of the device at these or any other conditions
above those indicated in the operation sections of this specification is not implied. Exposure to
absolute maximum rating conditions for extended periods of time may affect reliability.
DC ELECTRICAL CHARACTERISTICS
DATA PIN
(V
PUP
=2.8V to 6.0V; -40°C to +85°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
1-Wire Input High V
IH
2.2 V 1, 6
1-Wire Input Low V
IL
-0.3 0.8 V 1, 13
1-Wire Output Low @ 4mA V
OL
0.4 V 1
1-Wire Output High V
OH
V
PUP
6.0 V 1, 2
Input Load Current I
L
5 µA 3
Programming Voltage @ 10mA V
PP
11.5 12.0 V
DC ELECTRICAL CHARACTERISTICS
PIO PINs
(V
PUP
=2.8V to 6.0V; -40°C to +85°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Logic 1 (A) V
IHA
2.2 12 V 1, 6
Logic 0 (A) V
ILA
-0.3 0.6 V 1
Output Sink Current @ 4V (A) I
SA
See graph on page 30 mA 11, 12
Output Logic High (A) V
OHA
V
PUPA
12.0 V 1, 2
Logic 1 (B) V
IHB
2.2 6.0 V 1, 6
Logic 0 (B) V
ILB
-0.3 0.4 V 1
Output Sink Current @ 4V (B) I
SB
See graph on page 30 mA
Output Logic High (B) V
OHB
V
PUPB
6.0 V 1, 2
Input Resistance R
I
7 10 13 M W 9
DC ELECTRICAL CHARACTERISTICS V
CC
(V
PUP
=2.8V to 6.0V; -40°C to +85°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Logic 1 V
IHC
2.8 6.0 V 1, 10
Logic 0 V
ILC
-0.3 0.8 V 1
Input Current I
CC
4.0 µA 3
