Page 11: Atf1504asv(l)

11
ATF1504ASV(L)
1409H–PLD–09/02
Notes:
1. Not more than one output at a time should be shorted. Duration of short circuit test should not exceed 30 sec.
2. When microcell reduced-power feature is enabled.
Note:
Typical values for nominal supply voltage. This parameter is only sampled and is not 100% tested.
The OGI pin (high-voltage pin during programming) has a maximum capacitance of 12 pF.
DC and AC Operating Conditions
Commercial
Industrial
Operating Temperature (Ambient))
0
°
C - 70
°
C
-40
°
C - 85
°
C
V
CC
(3.3V) Power Supply
3.0V - 3.6V
3.0V - 3.6V
DC Characteristics
Symbol
Parameter
Condition
Min
Typ
Max
Units
I
IL
Input or I/O Low
Leakage Current
V
IN
= V
CC
-2
-10
µA
I
IH
Input or I/O High
Leakage Current
2
10
I
OZ
Tri-State Output
Off-State Current
V
O
= V
CC
or GND
-40
40
µA
I
CC1
Power Supply Current,
Standby
V
CC
= Max
V
IN
= 0, V
CC
Std Mode
Com.
60
mA
Ind.
75
mA
“L” Mode
Com.
5
µA
Ind.
5
µA
I
CC2
Power Supply Current,
Power-down Mode
V
CC
= Max
V
IN
= 0, V
CC
“PD” Mode
0.1
5
mA
I
CC3
(2)
Reduced-power Mode
Supply Current, Standby
V
CC
= Max
V
IN
= 0, V
CC
Std Power
Com
40
ma
Ind
55
V
IL
Input Low Voltage
-0.3
0.8
V
V
IH
Input High Voltage
1.7
V
CCIO
+ 0.3
V
V
OL
Output Low Voltage (TTL)
V
IN
= V
IH
or V
IL
V
CCIO
= Min, I
OL
= 8 mA
Com.
0.45
V
Ind.
0.45
Output Low Voltage (CMOS)
V
IN
= V
IH
or V
IL
V
CC
= Min, I
OL
= 0.1 mA
Com.
0.2
V
Ind.
0.2
V
V
OH
Output High Voltage
- 3.3V (TTL)
V
IN
= V
IH
or V
IL
V
CCIO
= Min, I
OH
= -2.0 mA
2.4
V
Output High Voltage
- 3.3V (CMOS)
V
IN
= V
IH
or V
IL
V
CCIO
= Min, I
OH
= -0.1 mA
V
CCIO
- 0.2
V
Pin Capacitance
Typ
Max
Units
Conditions
C
IN
8
pF
V
IN
= 0V; f = 1.0 MHz
C
I/O
8
pF
V
OUT
= 0V; f = 1.0 MHz
