ATF16LV8C
3
Note: 1. All I
CC
parameters measured with outputs open.
2. For DC characteristics, the test condition of V
CC
= Max corresponds to 3.6V.
AC Waveforms
(1)
Note: 1. Timing measurement reference is 1.5V. Input AC driving levels are 0.0V and 3.0V, unless otherwise specified.
DC Characteristics
Symbol Parameter Condition (2) Min Typ Max Units
I
IL
Input or I/O Low Leakage Current 0
≤
V
IN
≤
V
IL
(Max) -10
µ
A
I
IH
Input or I/O High Leakage Current 1.8
≤
V
IN
≤
V
CC
10
µ
A
I
CC1
(1) Power Supply Current
15 MHz, V
CC
= Max,
V
IN
= 0, V
CC,
Outputs Open
Com.
Ind. 55
60
mA
I
PD
(1) Power Supply Current, Power-down Mode
V
CC
= Max,
V
IN
= 0, V
CC
0.1 5
µ
A
I
OS
Output Short Circuit Current
V
OUT
= 0.5V;
V
CC
= 3V; T
A
= 25°C
-150 mA
V
IL
Input Low Voltage MIN < V
CC
< Max -0.5 0.8 V
V
IH
Input High Voltage 2.0 V
CC
+ 1 V
V
OL
Output Low Voltage
V
CC
= Min; All Outputs
I
OL
= 8 mA
0.5 V
V
OH
Output High Voltage
V
CC
= Min
I
OH
= -4 mA
2.4 V
I
OL
Output Low Current V
CC
= Min 8 mA
I
OH
Output High Current V
CC
= Min -4 mA
