MAX9750/MAX9751/MAX9755
2.6W Stereo Audio Power Amplifiers and
DirectDrive Headphone Amplifiers
_______________________________________________________________________________________ 5
ELECTRICAL CHARACTERISTICS (continued)
(V DD = PV DD = CPV DD = HPV DD = 5V, GND = PGND = CPGND = 0V, SHDN = V DD , C BIAS = 1µF, C1 = C2 = 1µF, speaker load
terminated between OUT_+ and OUT_-, headphone load terminated between HPOUT_ and GND, GAIN1 = GAIN2 = VOL = GAIN = 0V,
T
A
= T
MIN
to T
MAX
, unless otherwise noted. Typical values are at T
A
= +25°C.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
LOGIC INPUT ( SHDN , GAIN1, GAIN2, GAIN, VOL, IN1/ 2 )
Logic Input High Voltage V IH 2 V
Logic Input Low Voltage V IL 0.8 V
Logic Input Current I IN
±
1 µA
LOGIC INPUT HEADPHONE (HPS)
Logic Input High Voltage V IH 2 V
Logic Input Low Voltage V IL 0.8 V
Logic Input Current I IN 10 µA
Note 1: All devices are 100% production tested at room temperature. All temperature limits are guaranteed by design.
Note 2: Guaranteed by design. Not production tested.
Note 3: PSRR is specified with the amplifier input connected to GND through C
IN .
Note 4: Output power levels are measured with the thin QFN’s exposed paddle soldered to the ground plane.
Note 5: See Table 3 for details of the mute levels.
Note 6: The value of R
B dictates the minimum beep signal amplitude (see the Beep Input section).
