MAX12553
14-Bit, 65Msps, 3.3V ADC
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
DD
= 3.3V, OV
DD
= 2.0V, GND = 0, REFIN = REFOUT (internal reference), V
IN
= -0.5dBFS, CLKTYP = high, DCE = high, PD = low,
G/T = low, f
CLK
= 65MHz (50% duty cycle), T
A
= -40°C to +85°C, unless otherwise noted. Typical values are at T
A
= +25°C.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V
DD
to GND ...........................................................-0.3V to +3.6V
OV
DD
to GND........-0.3V to the lower of (V
DD
+ 0.3V) and +3.6V
INP, INN to GND ...-0.3V to the lower of (V
DD
+ 0.3V) and +3.6V
REFIN, REFOUT, REFP, REFN, COM
to GND................-0.3V to the lower of (V
DD
+ 0.3V) and +3.6V
CLKP, CLKN, CLKTYP, G/T, DCE,
PD to GND ........-0.3V to the lower of (V
DD
+ 0.3V) and +3.6V
D13–D0, DAV, DOR to GND....................-0.3V to (OV
DD
+ 0.3V)
Continuous Power Dissipation (T
A
= +70°C)
40-Pin Thin QFN 6mm x 6mm x 0.8mm
(derated 26.3mW/°C above +70°C)........................2105.3mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering 10s) ..................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
DC ACCURACY (Note 2)
Resolution
14
Bits
Integral Nonlinearity
INL
f
IN
= 3MHz (Note 5)
±1.4
±
4.2
LSB
Differential Nonlinearity
DNL
f
IN
= 3MHz, no missing codes over
temperature (Note 3)
±0.5
±
1.0
LSB
Offset Error
V
REFIN
= 2.048V
±0.1
±
0.55
%FS
Gain Error
V
REFIN
= 2.048V
±0.5
±4.9
%FS
ANALOG INPUT (INP, INN)
Differential Input Voltage Range
V
DIFF
Differential or single-ended inputs
±
1.024
V
Common-Mode Input Voltage
V
DD
/2
V
C
PAR
Fixed capacitance to ground
2
Input Capacitance
(Figure 3)
C
SAMPLE
Switched capacitance
4.5
pF
CONVERSION RATE
Maximum Clock Frequency
f
CLK
65
MHz
Minimum Clock Frequency
5
MHz
Data Latency
Figure 6
8.5
Clock
cycles
DYNAMIC CHARACTERISTICS
(differential inputs, Note 2)
Small-Signal Noise Floor
SSNF
Input at less than -35dBFS
-76.0
dBFS
f
IN
= 3MHz at -0.5dBFS (Note 8)
69.3
74.0
f
IN
= 32.5MHz at -0.5dBFS
73.9
f
IN
= 70MHz at -0.5dBFS
73.4
Signal-to-Noise Ratio
SNR
f
IN
= 175MHz at -0.5dBFS (Notes 7, 8)
68.0
71.0
dB
f
IN
= 3MHz at -0.5dBFS (Note 8)
69.2
73.9
f
IN
= 32.5MHz at -0.5dBFS
73.1
f
IN
= 70MHz at -0.5dBFS
73.1
Signal-to-Noise and Distortion
SINAD
f
IN
= 175MHz at -0.5dBFS (Notes 7, 8)
67.6
70.0
dB
