MAX12553
14-Bit, 65Msps, 3.3V ADC
______________________________________________________________________________________ 11
REFERENCE OUTPUT VOLTAGE
LOAD REGULATION
MAX12553 toc33
I REFOUT SINK CURRENT (mA)
V
REFOUT
(V)
0 -0.5 -1.0 -1.5
1.96
1.97
1.98
1.99
2.00
2.01
2.02
2.03
2.04
2.05
1.95
-2.0 0.5
+85°C
+25°C
-40°C
REFERENCE OUTPUT VOLTAGE
SHORT-CIRCUIT PERFORMANCE
MAX12553 toc34
I REFOUT SINK CURRENT (mA)
V
REFOUT
(V)
0 -1.0 -2.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
0
-3.0 1.0
+85°C
+25°C
-40°C
REFERENCE OUTPUT VOLTAGE
vs. TEMPERATURE
MAX12553 toc35
TEMPERATURE (°C)
V
REFOUT
(V)
60 35 10 -15
2.031
2.033
2.035
2.037
2.039
2.029
-40 85
REFP, COM, REFN
LOAD REGULATION
MAX12553 toc36
SINK CURRENT (mA)
VOLTAGE (V)
1 0 -1
0.5
1.0
1.5
2.0
2.5
3.0
0
-2 2
V REFP
V COM
V REFN
INTERNAL REFERENCE
MODE AND BUFFERED EXTERNAL
REFERENCE MODE
REFP, COM, REFN
SHORT-CIRCUIT PERFORMACE
MAX12553 toc37
SINK CURRENT (mA)
VOLTAGE (V)
4 0 -4
0.5
1.0
1.5
2.0
2.5
3.5
3.0
0
-8 12 8
V REFP
V COM
V REFN
INTERNAL REFERENCE
MODE AND BUFFERED
EXTERNAL REFERENCE MODE
Typical Operating Characteristics (continued)
(V DD = 3.3V, OV DD = 2.0V, GND = 0, REFIN = REFOUT (internal reference), V IN = -0.5dBFS, CLKTYP = high, DCE = high, PD = low,
G/T = low, f
CLK ≈ 65MHz (50% duty cycle), T A
= +25°C, unless otherwise noted.)
