High-ESD Profibus RS-485 Transceiver
MAX14770E
2 ______________________________________________________________________________________
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.
(Voltages referenced to GND.)
V
CC
.......................................................................-0.3V to +6.0V
RE, RO .......................................................-0.3V to (V
CC
+ 0.3V)
DE, DI ...................................................................-0.3V to +6.0V
A, B .....................................................................-8.0V to +13.0V
Short-Circuit Duration (RO, A, B) to GND .................Continuous
Continuous Power Dissipation (T
A
= +70NC)
8-Pin SOIC (derate 7.6mW/NC above +70NC) ............606mW
8-Pin TDFN (derate 24.4mW/NC above +70NC) ........1951mW
Junction-to-Ambient Thermal Resistance (B
JA
) (Note 1)
8-Pin SO ....................................................................132NC/W
8-Pin TDFN ..................................................................41NC/W
Junction-to-Case Thermal Resistance (B
JC
) (Note 1)
8-Pin SO ......................................................................38NC/W
8-Pin TDFN ....................................................................8NC/W
Operating Temperature Range
8-Pin SO ......................................................... -40NC to +85NC
8-Pin TDFN ................................................... -40NC to +125NC
Storage Temperature Range ............................ -65NC to +150NC
Junction Temperature Range ........................... -40NC to +150NC
Lead Temperature (soldering, 10s) ................................+300NC
ELECTRICAL CHARACTERISTICS
(V
CC
= +5V Q10%, T
A
= T
MIN
to T
MAX
, unless otherwise noted. Typical values are at V
CC
= +5V, T
A
= +25NC.) (Note 2)
ABSOLUTE MAXIMUM RATINGS
Note 1: Package thermal resistances were obtained using the method described in JEDEC specification JESD51-7, using a four-
layer board. For detailed information on package thermal considerations, refer to
www.maxim-ic/thermal-tutorial
.
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Power-Supply Range
V
CC
4.5
5.5
V
Supply Current
I
CC
DE = 1, RE = 0 or
DE = 0, RE = 0 or
DE = 1, RE = 1; no load
2.5
4
mA
Shutdown Supply
Current
I
SH
DE = 0, RE = 1
15
F
A
DRIVER
Differential Driver
Output
|V
OD
|
R
L
= 54I, V
DI
= V
CC
or GND; Figure 1
2.1
V
Differential Driver
Peak-to-Peak Output
V
ODPP
Figure 2 (Note 3)
4.0
6.8
V
Change in Magnitude
of Differential Output
Voltage
D
V
OD
R
L
= 54I; Figure 1 (Note 4)
-0.2
0
+0.2
V
Driver Common-
Mode Output Voltage
V
OC
R
L
= 54I; Figure 1
1.8
3
V
Change in Common-
Mode Voltage
D
V
OC
R
L
= 54I; Figure 1 (Note 4)
-0.2
+0.2
V
Driver Short-Circuit
Output Current
(Note 5)
I
OSD
0V P V
OUT
P +12V; output low
+250
mA
-7V P V
OUT
P V
CC
; output high
-250
Driver Short-Circuit
Foldback Output
Current (Note 5)
I
OSDF
(V
CC
- 1V) P V
OUT
P +12V; output low
-15
mA
-7V P V
OUT
P +1V; output high
+15
