MAX98314
Mono 3.2W Class D Amplifier
with Integrated Input Coupling Capacitors
Typical Operating Characteristics (continued)
(V
PVDD
= V
SHDN
= 5.0V, V
PGND
= 0V, A
V
= 6dB, R
L
= J, R
L
connected between OUT+ to OUT-, AC measurement bandwidth 20Hz
to 22kHz, T
A
= +25NC, unless otherwise noted.)
STARTUP RESPONSE
MAX98314 toc24
I SPKR_OUT
100mA/div
V SHDN
2V/div
SHUTDOWN RESPONSE
MAX98314 toc25
I SPKR_OUT
100mA/div
1ms/div
V SHDN
2V/div
NARROWBAND vs. FREQUENCY
MAX98314 toc27
FREQUENCY (Hz)
OUTPUT MAGNITUDE (dBV)
10k 1k 100
-120
-100
-80
-60
-40
-20
0
-140
10 100k
f = 1kHz
V
OUT = -60dBV
FREQUENCY (MHz)
OUTPUT MAGNITUDE (dBV)
10 1 0.1 100
WIDEBAND vs. FREQUENCY
MAX98314 toc26
-100
-80
-60
-40
-20
0
RBW = 100Hz
-120
