MAX98314
Mono 3.2W Class D Amplifier
with Integrated Input Coupling Capacitors
Ordering Information
WLP Applications Information
For the latest application details on WLP construction,
dimensions, tape carrier information, PCB techniques,
bump-pad layout, and recommended reflow temperature
profile, as well as the latest information on reliability test-
ing results, refer to
Application Note 1891: Wafer-Level
Packaging (WLP) and Its Applications . Figure 3 shows
the dimensions of the WLP balls used on the IC.
Figure 3. WLP Ball Dimensions
+Denotes a lead(Pb)-free/RoHS-compliant package.
PART TEMP RANGE PIN-PACKAGE
MAX98314EWL+ -40NC to +85NC 9 WLP
0.18mm
0.18mm
