Functional diagram/typical application circuit – Rainbow Electronics MAX98314 User Manual
Page 2
����������������������������������������������������������������� Maxim Integrated Products 2
MAX98314
Mono 3.2W Class D Amplifier
with Integrated Input Coupling Capacitors
Functional Diagram/Typical Application Circuit
IN-
C2
IN+
GAIN
A3
PVDD
SHDN
C3
CLASS D
MODULATOR
LOW-EMI
DRIVER
PVDD
A1
A2
OUT-
OUT+
PGND
LOW-EMI
DRIVER
PVDD
PGND
PGND
B1
UVLO/POWER
MANAGEMENT
CLICK-AND-POP
SUPPRESSION
2.5V TO 5.5V
10µF*
*SYSTEM BULK CAPACITANCE.
0.1µF
MAX98314
B3
C1
