MAX13485E/MAX13486E
Half-Duplex RS-485/RS-422 Transceivers in µDFN
_______________________________________________________________________________________ 7
Typical Operating Characteristics (continued)
(V
CC
= +5V, T
A
= +25°C, unless otherwise noted.)
RECEIVER PROPAGATION
vs. TEMPERATURE (MAX13485E)
MAX13485-86E toc13
TEMPERATURE ( °C)
PROPAGATION DELAY (ns)
60 35 10 -15
20
40
60
80
0
-40 85
t
RPHL
t RPLH
RECEIVER PROPAGATION
vs. TEMPERATURE (MAX13486E)
MAX13485-86E toc14
TEMPERATURE ( °C)
RECEIVER PROPAGATION (ns)
60 35 10 -15
10
20
30
40
0
-40 85
t
RPHL
t RPLH
400ns/div
DRIVER PROPAGATION (500kbps)
(MAX13485E)
DI
2V/div
MAX13485/86E toc15
A-B
5V/div
10ns/div
DRIVER PROPAGATION (16Mbps)
(MAX13486E)
DI
2V/div
MAX13485/86E toc16
A-B
5V/div
10ns/div
RECEIVER PROPAGATION (16Mbps)
(MAX13486E)
B
2V/div
MAX13485/86E toc17
RO
2V/div
A
2V/div
