Rainbow Electronics MAX16825 User Manual
Page 8
MAX16824/MAX16825
High-Voltage, Three-Channel Linear
High-Brightness LED Drivers
8
_______________________________________________________________________________________
BANDGAP AND
5V REGULATOR
THERMAL
SHUTDOWN
SHIFT
REGISTER
SHIFT
REGISTER
SHIFT
REGISTER
LATCH
LATCH
LATCH
LOGIC
200mV
OUT1
OUT2
OUT3
CS1
CS2
CS3
OE
LE
DOUT
CLK
DIN
REG
IN
GND
MAX16825
Figure 2. Internal Block Diagram (MAX16825)
