Introduction
Technical Specifications
Technical Specifications
Table 1-3 lists the technical specifications for the 9822 Downconverter with
HD/SD-SDI Input, Embedded Audio, Frame Sync, and Timecode/Closed
Caption/AFD Support card.
Table 1-3
Technical Specifications
Item
Characteristic
Part number, nomenclature
9822 Downconverter with HD/SD-SDI Input, Embedded Audio,
Frame Sync, and Timecode/Closed Caption/AFD Support
Installation/usage environment
Intended for installation and usage in frame meeting openGear™
modular system definition.
Power consumption
< 20 Watts maximum
Environmental:
Operating temperature:
Relative humidity (operating or storage):
32° – 104° F (0° – 40° C)
< 95%, non-condensing
Frame communication
10/100 Mbps Ethernet with Auto-MDIX.
Indicators
Card edge display and indicators as follows:
• 4-character alphanumeric display
• Status/Error LED indicator
• Input Format LED indicator
Controls
Card edge switches as follows:
• Menu Enter pushbutton switch
• Menu Exit pushbutton switch
• Up/down selection toggle switch
Internal Tone Generators
Four built-in tone generators, each configurable for 18 discrete
sine wave frequencies ranging from 50 Hz to 16 kHz.
Generator source signal level is equivalent to -20 dBu.
Resolution:
10-bit video data path
Serial Digital Video Input
Data Rates Supported:
SMPTE 292 HD-SDI: 1.485 Gbps or 1.485/1.001 Gbps
SMPTE 259M-C SD-SDI: 270 Mbps
Impedance:
75
Ω
terminating
Equalization (HD):
328 ft (100 m) Belden 1694A
