MODEL 5600 & 5600 ECONOMINDER ®
Job Specification Sheet
Printed in U.S.A.
• JOB NO. __________________________________________________________
• *MODEL NO. ______________________________________________________
• WATER TEST ______________________________________________________
• CAPACITY PER UNIT_____________ MAX. ___________ PER REGENERATION
• MINERAL TANK SIZE DIA.________ HEIGHT _________
• BRINE TANK SIZE & SALT SETTING PER REGENERATION:
• _________________________________________________________________
Page 2
CONTROL VALVE SPECIFICATIONS
Type of Timer
A) Std C) 7 Day E) Meter, Std.
B) “L” D) 12 Day F) Meter, Ext.
Day/Time of Regeneration____________________________________
Drain Line Flow Control______________________________________ gpm
Brine Refill Rate____________________________________________ gpm
Injector Size_______________________________________________
Meter Gallon Setting________________________________________ gal.
TYPICAL CONTROL VALVE INFORMATION
Due to varying water conditions, tank sizes and water pressures, the above settings should be used only as a
guideline.
1 B.L.F.C. (Brine Line Flow Control). Refill Rate for Filling Brine Tank.
2
D.L.F.C. (Drain Line Flow Control). Backwash and Rapid Rinse Flow Rates.
Tank Size
Dia. Injector
Slow Rinse
Rate (gpm)
@ 40 PSI
Brine Draw
Rate (SPM)
@ 40 PSI
B.L.F.C.
1
D.L.F.C.
2
6
″
7
″
# 0 Red
# 0 Red .31 gpm
.31 gpm .28 gpm
.28 gpm .5 gpm
.5 gpm 1.2 gpm
1.2 gpm
8
″
9
″
10
″
# 1 White
# 1 White
# 1 White
.45 gpm
.45 gpm
.45 gpm .38 gpm
.38 gpm
.38 gpm .5 gpm
.5 gpm
.5 gpm 1.5 gpm
2.0 gpm
2.4 gpm
12
″
13
″
# 2 Blue
# 2 Blue .84 gpm
.84 gpm .56 gpm
.56 gpm 1.0 gpm
1.0 gpm 3.5 gpm
4.0 gpm
14
″
16
″
# 3 Yellow
# 3 Yellow 1.0 gpm
1.0 gpm .63 gpm
.63 gpm 1.0 gpm
1.0 gpm 5.0 gpm
7.0 gpm
