Daystar KN09105BK User Manual
Installation instructions
KN09105 – 2005-UP Nissan Xterra/Frontier 2" Lift
Instruction Sheet - P11074-01.doc
Page 1 of 2
© 20066 Daystar Products International Inc
.
www.DaystarWeb.com
Tech Support:
Phone: 623.907.0081 / Fax: 623.907.0088
841 South 71
st
Avenue; Phoenix, AZ 85043
INSTALLATION INSTRUCTIONS
1. Read instructions completely, verify bill of materials
and determine if you have the correct tools before
beginning installation.
Front Installation
2. Raise vehicle until front tires are clear, support the vehicle.
3. Remove the front tire and wheel assembly.
4. Remove the lower stabilizer link bolt and move sway-bar assembly out of way.
5. Remove the upper ball joint nut.
6. Separate the upper ball joint from the spindle.
7. Remove the strut assembly and install the strut spacer see Fig. 1.
8. Rotate the strut (with spacer installed) 180 º.
9. Reassemble spindle and ball joint
Rear Installation
10. Remove spare tire.
11. Raise vehicle until rear tires are clear, support the vehicle.
12. Remove rear sway-bar bolt and swing the bar and linkage out of the way. Remove the shocks.
13. Support the rear axle and remove the OE shackles and OE spring bushings.
14. Install new Daystar Greaseable shackles. See Fig 2.
15. Reconnect the swaybar and install optional new shocks (22in. extend length, 13.5 compressed
Eylet/Eyelet)
16. Torque all bolts to factory specs and check after 50 miles.
17. After installation of kit; alignment should be checked and adjusted if necessary.
Bill of Materials
Part #
Description
Qty
S11014 SHACKLES
(REAR)
2
M03678 SPRING
BUSHING
4
M03679 SPRING
BUSHING
4
S11010 STEEL
TUBING
0.584X0.750X3.950
2
S11011 STEEL
TUBING
0.584X0.750X2.865
2
S10205 9/16-12
NYLOCK
NUTS
4
S10199
9/16-12 X 4-1/2" GR5 GREASABLE BOLT
2
S10388
9/16-12 X 5-1/2" GR5 GREASABLE BOLT
2
S11015
9/16 SAE NARROW WASHER
8
S11013
STRUT SPACER (FRONT)
2
S10203
7/16-14 NYLOCK NUTS (FRONT)
6
S11016
7/16 SAE NARROW WASHER (FRONT)
6
Tools required
Description:
Standard sockets, hand tools Etc.
Hydraulic Lift is Recommended
Floor Jacks / Jack Stands
Ball joint separator
Shown above: S Model with KN09105 2” lift and 32X10.50X16 BFG AT’s
