Instruction Sheet P11032-01

2008 Daystar Products Intl
Page 4 of 4

Rear instructions sheet.

Rear Bill of Materials
Part No Description Qty
S10967 BLOCK

S10958 U-BOLT

S10959 NUT

S10963 WASHER

WARNING

This vehicle has been modified to enhance its performance. The steering, braking and handling of this vehicle will differ from standard passenger cars and trucks,
This vehicle handles differently from an ordinary vehicle in driving conditions which may occur on streets, highways and off road.
Avoid unnecessary abrupt maneuvers, sudden stops, sharp turns and other driving conditions that could cause loss of control, possibly leading to a roll over or other
accident that could result in serious injury or death to driver and passengers. If larger tires are installed the speedometer will read lower than the vehicles actual
speed.

DRIVE WITH CARE, REDUCE SPEED AND WEAR SEAT BELTS AT ALL TIMES.

1. OE

SPRING

2. LIFTING

BLOCK

3. U-BOLT

9/16-18

4. OE

U-BOLT

PLATE

5. NUT&WASHER

15. Jack up the rear of the truck and place 2 jack stands under the rear frame and lower down and remove

the rear wheels.

16. Place the floor jack under the rear axel and remove the 4 u-bolts and nuts and lower down the axle

enough to fit the lifting blocks into position.

17. Install lifting block, new u-bolts, washers and hex nuts. Torque to 95ft-lbs
18. Install the rear wheels and place back on the ground.
