Vehicle base for the
INSTALLATION INSTRUCTIONS
1. Move the passenger seat back to its rearmost position and remove the front seat rail bolts on the passenger side.
This will require a 14mm socket wrench. If installing into a 2010/2011 Camry, you will need the two short sections of
pipe, stand-offs, and the longer seat leg bolts. See notes below then proceed with remaining instructions.
2. Without moving the seat, place the No-Drill™ base over the front of the seat frame legs.
3. Align the holes in the base with those of the seat frame legs. The pedestal platform should be near the console.
4. Re-install the seat bolts and fully tighten.
For 2010/2011 Camry, place the stand offs over the seat leg holes. Next rest the base over the stand offs and align the
holes through to the floor board. Start the thread of the supplied bolts into the floor board by hand. Once they are
started, use a 17mm socket to tighten. Tighten the center bolt first, then the bolt closest to the door. The bolt closest to
the door will require the use of a 17mm box end wrench to fully tighten the bolt for clearance reasons. The base WILL
touch the center hump of the vehicle and the carpeting in some vehicles due to variations in the carpeting. If this base
is used with the RAM Tele-Pole™ system, the glove box door will rest on the pole when open. It is still possible to fit
ones hand into the glove box to reach stored items.
This document, including images, may not be reproduced partly or fully without the expressed written consent of National Products, Inc.
RAM No-Drill
TM
Seat Bases
National Products, Inc.
Item Number
RAM-VB-137 & RAM-VB-137-SW1
TOYOTA TUNDRA (2012-2013)
TOYOTA CAMRY (2006-2011)
TOYOTA COROLLA (2003-2008)
TOYOTA MATRIX (2003-2008)
PONTIAC VIBE (2003-2008)
