Vehicle base for the
INSTALLATION INSTRUCTIONS
Note that the seat leg bolt on the passenger side closest to the door may be beneath a piece of plastic trim. Remove
only the round center cover and store for later use.
1. Move the passenger seat back to its rearmost position.
2. Remove the round plastic plug cover using a small screw driver. Gently pry this up to expose the seat leg bolt.
Store this cover for later use.
3. Remove both of the front seat rail bolts on the passenger side.
4. Once the bolts are removed, store the bolt that was removed from under the plastic cover for later use.
5. Place the stand off provided over the seat frame leg hole closest to the passenger door.
6. Align the holes in the base with those of the seat frame legs. The hole closest to the passenger side door should
rest over the stand off providing clearance for the plastic trim piece remaining.
7. Pass the factory bolt nearest the center of the vehicle through the No-Drill™ base and begin the thread by hand.
8. Pass the longer seat leg bolt provided in the kit through the washer included in the kit, through the No-Drill™ base,
through the stand off, and begin thread by hand into the floor board.
9. Once both seat leg bolts have been started, fully tighten using a socket wrench.
10. After a week of use, check seat leg bolt and re-tighten if necessary.
This document, including images, may not be reproduced partly or fully without the expressed written consent of National Products, Inc.
RAM No-Drill
TM
Seat Bases
National Products, Inc.
Item Number
RAM-VB-134 & RAM-VB-134-SW1
NISSAN TITAN (2004-2013)
NISSAN ARMADA (2004-2013)
INFINITI QX56 (2004-2010)
