6. Operation
PNEG-1775 Vane Axial Heater - Canadian
23
BTUs for Gauge Pressure (PSI) Reading Natural Gas Models
(Approximate)
High Temperature
Low Temperature
Gauge Pressure (PSI) Reading to Maintain Temp (Approximate)
Diameter
Operating Pressure (PSI)
1
2
3
4
5
6
7
8
9
10
18"
659,337
831,044
989,238
1,135,039 1,269,526 1,393,734 1,508,661 1,615,262 1,714,449 1,807,097
24"
912,577
1,150,234 1,369,188 1,570,989 1,757,129 1,929,044 2,088,112 2,235,656 2,372,940 2,501,172
28"
1,314,110 1,656,337 1,971,631 2,262,224 2,530,266 2,777,823 3,006,882 3,219,345 3,417,034 3,601,688
Diameter
Operating Pressure (PSI)
1
2
3
4
5
6
7
8
9
10
18"
184,797
232,922
277,261
318,125
355,819
390,631
422,843
452,720
480,520
506,487
24" and 28"
82,132
103,521
123,227
141,389
158,142
173,614
187,930
201,209
213,565
225,105
Diameter
Static
Pressure
Heat Rise (F)
60
80
100
120
140
160
180
3 HP - 18"
1"
Low Temp
Low Temp
2
2
3
4
5
2"
Low Temp
Low Temp
Low Temp
1
2
3
3
5 HP - 24"
1"
1
2
3
5
6
8
10
2"
Low Temp
2
3
4
5
6
8
3"
Low Temp
Low Temp
2
3
3
4
5
7 HP - 24"
1"
1
2
4
5
7
8
10
2"
1
2
3
4
6
7
9
3"
Low Temp
1
2
3
4
5
7
4"
Low Temp
Low Temp
1
2
2
3
4
10 HP - 24"
1"
1
3
4
6
8
10
10
2"
1
2
3
5
6
8
10
3"
Low Temp
2
3
4
5
6
7
4"
Low Temp
Low Temp
1
2
3
3
4
15 HP - 28"
1"
1
3
4
6
8
10
10
2"
1
2
3
5
6
8
10
3"
1
2
3
4
5
7
8
4"
Low Temp
1
2
3
4
5
6
5"
Low Temp
Low Temp
1
2
2
3
4
