6. Operation
22 PNEG-1775 Vane Axial Heater - Canadian
BTUs for Gauge Pressure (PSI) Reading Propane Models
(Approximate)
High Temperature
Low Temperature
Gauge Pressure (PSI) Reading to Maintain Temp (Approximate)
Diameter
Operating Pressure (PSI)
2 4 6 8 10 12 14 16 18 20
24" 1,821,128 2,487,296 3,054,193 3,539,643 3,960,025 4,330,275 4,663,886 4,972,904 5,267,934 5,558,136
28" 2,622,425 3,581,706 4,398,038 5,097,085 5,702,436 6,235,596 6,715,995 7,160,981 7,585,825 8,003,715
Diameter
Operating Pressure (PSI)
2 4 6 8 10 12 14 16 18 20
24" and 28" 455,282 621,824 763,548 884,911 990,006 1,082,569 1,165,971 1,243,226 1,316,983 1,389,534
Diameter
Static
Pressure
Heat Rise (F)
60 80 100 120 140 160 180
5 HP - 24"
1" 1 3 4 6 7 9 12
2" 1 2 3 5 6 8 10
3" Low Temp 1 2 3 4 5 7
4" Low Temp Low Temp 1 2 2 3 4
7 HP - 24"
1" 2 3 5 6 8 11 13
2" 1 2 4 5 7 9 11
3" Low Temp 2 3 4 5 7 8
4" Low Temp Low Temp 1 2 3 4 5
10 HP - 24"
1" 2 3 5 7 10 12 16
2" 1 3 4 6 8 10 12
3" Low Temp 2 3 4 6 7 9
4" Low Temp Low Temp 2 2 3 4 5
15 HP - 28"
1" 2 3 5 7 9 12 16
2" 2 3 4 6 8 10 13
3" 1 2 3 5 6 8 10
4" Low Temp 2 3 4 5 6 8
5" Low Temp Low Temp 2 2 3 4 5
