6. Control Boxes
PNEG-1471 Vision Series Model 2400 Portable Dryer 73
Fan/Heater Control Box Parts List (See Figure 6A)
Ref # Part # Description All Fan/Heaters
* D01-1992 Control Box Lid 1
1 D01-2105 Control Box Back Panel 1
2 D01-2106 Control Left Side 1
3 D01-2107 Control Box Right Side 1
4 D01-2110 Control Box Front Panel 1
5 D03-0696 Control Box Latch 1
6 D01-2108 Control Box Base 1
7 006-1389-3 Nylon Bushing-2" Diameter 1
8 D01-2111 Control Box Wall 1
9 E160-1137 Ground Lug, #TA-2 2
10 HH-1105 Nylon Bushing-11/16" I.D. 3
11 HF-4624 Fenwal Flame Detection Board 1
12 D01-2109 Fenwal Board Bracket 1
13 D01-1981 Mounting Bracket Heater Board 1
14 D01-0730 Touch Control Fan/heater PCB Assembly 1
15 D03-0013 Din Rail Mounting 39.37" Long 0.45
16 D01-0531 Terminal-block Entrelec 4 mm 28
17 D01-0532 Terminal-blank End Protector 11
18 D01-0534 Terminal - Entrelec Ground Block 1
19 D01-0533 Terminal - Entrelec End Stop 8
20 D03-0511 Points, Auxillary for TEC 1
21 See Chart below for Part Numbers
22 See Chart below for Part Numbers
23 E240-1148 Connector 4 Pin 0.200 PCB Plug 2
24 D01-0460 Term Strip 10 Position 1
25 E240-1155 Connector 3 Pin 0.200 PCB Plug 1
26 E240-1154 Connector 5 Pin 0.200 PCB Plug 1
* Not Shown
Ref # Description 10-12 HP Fan Motors (2812, 3612 Fan/heaters)
220V 1 PH 208V 3 PH 220V 3 PH 440V 3 PH 575V 3 PH
21 Overload D03-0483 D03-0482 D03-0482 D03-0476 D03-0475
22 Contactor D03-0495 D03-0494 D03-0494 D03-0492 D03-0490
10-16 HP Fan Motors (3615 Fan/heaters)
220V 1 PH 208V 3 PH 220V 3 PH 440V 3 PH 575V 3 PH
21 Overload D03-0485 D03-0483 D03-0483 D03-0477 D03-0478
22 Contactor D03-0497 D03-0494 D03-0494 D03-0492 D03-0491
10-16 HP Fan Motors (4015 Fan/heaters)
220V 1 PH 208V 3 PH 220V 3 PH 440V 3 PH 575V 3 PH
21 Overload D03-0485 D03-0483 D03-0483 D03-0478 D03-0478
22 Contactor D03-0497 D03-0494 D03-0494 D03-0491 D03-0491
25 HP Fan Motors (4025 Fan/heaters)
220V 1 PH 208V 3 PH 220V 3 PH 440V 3 PH 575V 3 PH
21 Overload N/A D03-0485 D03-0485 D03-0482 D03-0479
22 Contactor N/A D03-0496 D03-0496 D03-0494 D03-0492
