Series 2000 Autoflow Operation Autoflow Series Drying Rates
Shelled Corn
(Metric Measurements)
Insufficient burner BTUs for 7 deg. C ambient
temp.
Ratings exclude loading time.
1/4 CFM/bu
cooling rate.
Est. at ambient temp 7 deg. C, rel.humidity
65%.
Use only as a guide, conditions will vary
capacities.
AUTOFLOW SERIES 9.14m Dia. 2- Fan 10.97m Dia. 1-Fan 10.97m Dia. 2-Fan
FAN & Plenum Moisture Minutes Minutes Minutes
HEATER Temp. Content Between Between Between
Unit(s) C
o
Wet Basis MT / hr Dumps MT / hr Dumps MT / hr Dumps
20% 23.9 18.9 25.2 25.8
71 25% 15.1 29.9 16.0 40.7
11.19 kW 30% 9.4 47.9 10.0 65.2
91.44 cm 20% 30.5 14.8 32.3 20.1
82 25% 19.3 23.4 20.4 31.8
1.125 30% 12.1 37.4 12.8 51.0
Million 20% 35.7 * 12.6 37.8 * 17.2
kCal 93 25% 22.6 * 19.9 24.0 * 27.2
30% 14.1 * 32.0 15.0 * 43.5
20% 29.3 15.4 32.2 20.2
71 25% 18.6 24.3 20.4 31.9
11.19 kW 30% 11.6 39.0 12.8 51.1
101.60 cm 20% 37.5 12.0 41.2 15.8
82 25% 23.8 19.0 26.1 24.9
1.5 30% 17.8 30.4 16.3 39.9
Million 20% * 43.9 * 10.2 * 48.3 * 13.4
kCal 93 25% * 27.8 * 16.2 * 30.6 * 21.3
30% * 17.4 * 26 * 19.1 * 34.1
20% 20.8 31.3 36.9 17.6
71 25% 13.2 49.4 23.4 27.8
22.37 kW 30% 8.2 79.1 14.6 44.6
106.68 cm 20% 26.6 24.4 47.2 13.8
82 25% 16.9 38.6 29.9 21.7
2.5 30% 10.5 61.8 18.7 34.8
Million 20% 31.2 20.8 55.3 11.7
kCal 93 25% 19.7 32.9 35.0 18.6
30% 12.3 52.8 21.9 29.8
20% 24.1 26.9
71 25% 15.3 42.6
29.83 kW 30% 9.6 68.2
106.68 cm 20% 30.9 21.0
82 25% 19.6 33.3
2.5 30% 12.2 53.3
Million 20% 36.2 18.0
kCal 93 25% 22.9 28.4
30% 14.3 45.5
