Series 2000 Autoflow Operation
2 8
DRYING RATES
T
OP
D
RY
A
UTOFLOW
S
ERIES
D
RYING
R
ATES FOR
S
HELLED
C
ORN
*Insufficient burner BTUs for 45 deg. ambient temp. Est. at ambient temp 45 deg. F, rel.humidity 65%
Use only as a guide, conditions will vary capacities. 1/4 cfm cooling
AUTOFLOW SERIES 21' Dia. 1-Fan 24' Dia. 1-Fan 30' Dia. 1-Fan
FAN & Plenum Moisture Minutes Minutes Minutes
HEATER Temperature Content Between Between Between
Unit(s) F
o
Wet Basis Bu / hr Dumps Bu / hr Dumps Bu / hr Dumps
20% 499 17.4 528 21.6 557 31.9
160 25% 316 27.6 334 34.1 353 50.4
15 H.P. 30% 197 44.2 209 54.6 220 80.8
36" FAN 20% 639 13.6 * 675 * 16.8 * 713 * 24.9
180 25% 404 21.5 * 428 * 26.6 * 451 * 39.4
3.5 30% 253 34.5 * 267 * 42.6 * 282 * 63.1
Million 20% * 748 * 11.6 * 791 * 14.4 * 835 * 21.3
BTU 200 25% * 474 * 18.4 * 501 * 22.7 * 529 * 33.6
30% * 296 * 29.5 * 313 * 36.4 * 330 * 53.9
20% 584 14.9 648 17.5 711 25.0
160 25% 370 23.5 411 27.7 450 39.5
15 H.P. 30% 231 37.7 256 44.4 281 63.3
40" FAN 20% 748 11.6 * 830 * 13.7 * 909 * 19.5
180 25% 473 18.4 * 525 * 21.6 * 576 * 30.9
6.25 30% 296 29.5 * 328 * 34.7 * 360 * 49.5
Million 20% * 875 * 9.9 * 971 * 11.7 * 1,065 * 16.7
BTU 200 25% * 554 * 15.7 * 615 * 18.5 * 674 *26.4
30% * 346 * 25.2 * 384 * 29.6 * 421 * 42.2
20% 740 15.4 806 22.0
160 25% 469 24.3 511 34.8
30 H.P. 30% 293 38.9 319 55.8
42" FAN 20% 947 12.0 1,032 17.2
180 25% 600 19.0 653 27.2
10.25 30% 375 30.4 408 43.6
Million 20% 1,109 10.2 1,208 14.7
BTU 200 25% 702 16.2 765 23.2
30% 439 25.9 478 37.2
20% 920 19.3
160 25% 583 30.5
40 H.P. 30% 364 48.9
42" FAN 20% 1,178 15.1
180 25% 746 23.8
10.25 30% 466 38.2
Million 20% 1,379 12.9
BTU 200 25% 873 20.3
30% 545 32.6
