Chapter 4: intermediate platform assembly – Grain Systems PNEG-1936 User Manual
Page 50
Chapter 4: Intermediate Platform Assembly
Assembly of Platform Planks to Inside Platform Rail and Knee
Brace
Figure 4-3 Assembly of Platform Planks to Inside Platform Rail and Knee Brace
Assembly of platform plank to inside platform rail and knee brace
Assembly of platform plank to inside platform rail and knee brace
Table 4-9 Parts list
Part Number
Description
Quantity
STR-1173
Platform plank
2
S-7927
3/8 x 1 in. flange bolt
8
S-968
3/8 in. flange nut
8
50
PNEG-1936 Top Dryer
