Page 11
- 11 -
1200 Series Parts Manual
ITEM
NUMBER
PART
NUMBER
DESCRIPTION
1214
1216
1218
1220
1222
1226
1
D01-1136Y PLENUM CLOSURE DOOR ANGLE, RH
6
7
8
9
10
12
2
D01-1136X PLENUM CLOSURE DOOR ANGLE, LH
7
8
9
10
11
13
3
D01-0109
HOPPER BULKHEAD
12
14
16
18
20
24
4
D01-0004
GUSSET PLATE
16
18
20
22
24
28
5
D01-0005
SIDE LEG
10
12
14
16
16
20
6
D01-0007
CORNER LEG
6
6
6
6
8
8
7
D01-0011
HITCH BRACKET, LH
1
1
1
1
1
1
8
D01-0012
HITCH BRACKET, RH
1
1
1
1
1
1
9
D01-0008
FRONT & REAR FRAME TIE CHANNEL
4
4
4
4
6
6
10
D01-1374
BOTTOM AUGER BEARING PLATE
1
1
1
1
1
1
11
D21-0011
FRAME RAIL, 14' RIGHT
1
11
D01-0538
FRAME RAIL, 16' RIGHT
1
11
D31-0044
FRAME RAIL, 18' RIGHT
1
11
D61-0002
FRAME RAIL, 20' RIGHT
1
11
D101-0002 FRAME RAIL, 22' RIGHT
1
11
D71-0001
FRAME RAIL, 26' RIGHT
1
11A
D21-0010
FRAME RAIL, 14' LEFT
1
11A
D01-0537
FRAME RAIL, 16' LEFT
1
11A
D31-0043
FRAME RAIL, 18' LEFT
1
11A
D61-0001
FRAME RAIL, 20' LEFT
1
11A
D101-0001 FRAME RAIL, 22' LEFT
1
11A
D71-0002
FRAME RAIL, 26' LEFT
1
12
D01-0048
TROUGH PANEL
14
16
18
20
22
26
13
D01-1512
PLATE, CROSS CHANNEL SEAL W/TABS
1
1
1
1
2
2
14
D01-1291
HANGER BEARING "C" CHANNEL
1
1
1
1
2
2
15
D01-1290
HANGER BEARING "J" PLATE
2
2
2
2
4
4
16
D02-0028
CLEVIS PIN 5/16" x 1 3/4"
32
32
40
40
48
56
17
D31-0148
METER ROLL WASHER
16
16
20
20
24
28
18
D02-0061
METER ROLL SUPPORT BEARING
6
6
8
8
10
12
19
D01-0177
SUPPORT STRAP
7
8
9
10
11
13
20
D01-1511
PLATE, END CHANNEL SEAL W/TAB
2
2
2
2
2
2
21
D31-0120
DISCHARGE PLATE
1
1
1
1
1
1
22
D31-0031
METER ROLL, FRONT
2
4
2
4
2
2
23
D31-0030
METER ROLL, INTERMEDIATE
4
4
6
6
8
10
24
D31-0029
METER ROLL, REAR
2
2
2
2
The part number list above covers all parts pointed out on pages 8, 9, and 10.
Meter Rolls and Their Placement in the Dryer
