2002 Top Dry Service School
18
Top Dry Sidewall Gauges
NOMINAL DIA. NUMBER OF RINGS Sidewall Sidewall Sidewall Sidewall Sidewall Sidewall Sidewall Sidewall Sidewall Sidewall Sidewall
OF SIDEWALL (Ft) OF SIDEWALL Base Ring Ring #2 Ring #3 Ring #4 Ring #5 Ring #6 Ring #7 Ring #8 Ring #9 Ring #10 Ring #11
18 5 20ga 20ga 20ga 20ga 20ga
18 6 20ga 20ga 20ga 20ga 20ga 20ga
18 7 20ga 20ga 20ga 20ga 20ga 20ga 20ga
21 5 20ga 20ga 20ga 20ga 20ga
21 6 20ga 20ga 20ga 20ga 20ga 20ga
21 7 20ga 20ga 20ga 20ga 20ga 20ga 20ga
21 8 18ga 20ga 20ga 20ga 20ga 20ga 20ga 20ga
24 5 20ga 20ga 20ga 20ga 20ga
24 6 20ga 20ga 20ga 20ga 20ga 20ga
24 7 18ga 20ga 20ga 20ga 20ga 20ga 20ga
24 8 18ga 18ga 20ga 20ga 20ga 20ga 20ga 20ga
24 9 17ga 18ga 18ga 20ga 20ga 20ga 20ga 20ga 20ga
24 10 17ga 17ga 18ga 18ga 18ga 20ga 20ga 20ga 20ga 20ga
27 5 18ga 18ga 18ga 20ga 20ga
27 6 18ga 18ga 18ga 18ga 20ga 20ga
27 7 18ga 18ga 18ga 18ga 18ga 20ga 20ga
27 8 17ga 18ga 18ga 18ga 18ga 18ga 20ga 20ga
27 9 17ga 17ga 18ga 18ga 18ga 18ga 18ga 20ga 20ga
27 10 17ga 17ga 17ga 18ga 18ga 18ga 18ga 18ga 20ga 20ga
30 5 18ga 18ga 18ga 18ga 20ga
30 6 18ga 18ga 18ga 18ga 18ga 20ga
30 7 17ga 18ga 18ga 18ga 18ga 18ga 20ga
30 8 17ga 17ga 18ga 18ga 18ga 18ga 18ga 20ga
30 9 17ga 17ga 17ga 18ga 18ga 18ga 18ga 18ga 20ga
30 10 16ga 17ga 17ga 17ga 18ga 18ga 18ga 18ga 18ga 20ga
30 11 16ga 17ga 17ga 17ga 17ga 18ga 18ga 18ga 18ga 18ga 20ga
36 5 17ga 18ga 18ga 18ga 20ga
36 6 17ga 18ga 18ga 18ga 18ga 20ga
36 7 16ga 17ga 18ga 18ga 18ga 18ga 20ga
36 8 16ga 16ga 17ga 18ga 18ga 18ga 18ga 20ga
36 9 16ga 16ga 16ga 17ga 18ga 18ga 18ga 18ga 20ga
36 10 15ga 16ga 16ga 16ga 17ga 18ga 18ga 18ga 18ga 20ga
36 11 14ga 15ga 15ga 16ga 16ga 17ga 18ga 18ga 18ga 18ga 20ga
Technical Data
