46 PNEG-588-04 Deluxe Downwind Heater Installation and Operation
11. Miscellaneous Parts by Description
Part # Description Part # Description
HF-7200 250° Bin High-Limit Assembly HF-7719 Downwind Heater Box - CNC OPS
HF-7431 Access Panel Assembly Downwind Heater HF-7653 Downwind Housing Bottom: 10-15
HF-7287 Access Panel Bracket - Downwind Heaters HF-7781 Downwind Housing Bottom: 20-30
HF-7288 Access Panel Downwind Heater HF-7803 Downwind Housing Bottom: 40
D03-0099 Adapter Tab 0.187" x 0.187" HF-7662 Downwind Housing Profile Bottom: 10-15
HF-7698 Backing Plate - Heater Controls HF-7786 Downwind Housing Profile Bottom: 20-30
D63-0006 Block, Contact N.O. HF-7805 Downwind Housing Profile Bottom: 40
S-6606 Flange Bolt 5/16"-18 x 3/4" ZN Grade 5 HF-7661 Downwind Housing Profile Top: 10-15
S-1101 Bolt, HHCS 1/4"-20 x 1/2" ZN Grade 2 HF-7785 Downwind Housing Profile Top: 20-30
756-1485-9 Boot - For Flame Rod and Igniter-A HF-7804 Downwind Housing Profile Top: 40
HF-7665 Burner Mounting Grip: Downwind Heater FH-7050 Elbow, 3/8" 90° PVC w/ Nut
415-4312-5 Burner Sub-Assembly CFDH27 HF-7655 Downwind Housing Side: L.H. 10-15
415-4434-7 Burner Sub-Assembly CFDH30/33 D03-0696 Latch, Farm Fans Control Box
HH-1096 Clamp, 1/2" Conduit HF-7784 Downwind Housing Side: L.H. 20-30/40
HF-7710 Conduit Assembly - Downwind Flame Rod Wire HF-7654 Downwind Housing Side: R.H. 10-15
415-4222-6 Conduit Assembly - Downwind Heater to Fan HF-7783 Downwind Housing Side: L.H. 20-30/40
HF-7709 Conduit Assembly - Downwind Ignition Wire FH-7404 Fuse, 2 Amp 1/4" x 1-1/4" Slow Blow
HF-7723 Conduit Assembly - Liquid Solenoid w/ Din DW HF-7652 Downwind Housing Top: 10-15
HF-7722 Conduit Assembly - Main Solenoid w/ Din DW HF-7780 Downwind Housing Top: 20-30
FH-1310 Connector, Cord HEYCO #3231 HF-7802 Downwind Housing Top: 40
069-1376-8 Control Box Lid - Poly Blank 025-1203-6 Plug, Hole - 7/8" Diameter Liquid Tight
HF-7694 Control Box Sub-Assembly: Downwind Deluxe THH-4071 Elbow, 1/2"-90° SCH 40 Black
HF-7796 Cover Plate - Downwind Vaporizer Hole HH-4847 Elbow, 1/2"-90° SCH 80 Black
DC-889 Decal, Danger High Voltage THH-4153 Elbow, 1" x 1/2" - 90° Reducing SCH 40
420-1422-5 Decal, 115 Volt 1 Phase FH-1309 Lock Nut 1/2" with Pipe Threads
DC-113 Decal, Air Flow THH-4149 Elbow, 3/4"-1/2" Reduce SCH 40
DC-1224 Decal, Danger High Voltage (LG) 90-0009 Lamp, Oil Tight 1/4" TAB 120V
DC-1254 Decal, Ground Lug 24 Per Sheet E160-1137 Lug Ground, #TA-2 (CSA)
DC-108 Decal, High-Limit Button THH-4179 Flame Sensor 6" Long Rod
DC-1718 Decal, Warning Heater Fire S-2052 Foam Strip 1/8" Thread x 1/2" Wide
DC-1559 Decal, Warning: DC-1225/DC-1227 025-1202-8 Gasket - Adapter Plate/Motor C
DC-1170 Decal, Deluxe Heater Wiring HH-2984 Gauge, Pressure 0-30# LP
DC-1702 Decal: Caution Use TSTAT w/ Heater HF-7379 Heater Cover Plate 1996<
FH-7038 Fitting, Sealtite PVC 3/8" HF-7509 Hose, 1/2" x 18" LP Gas Assembly
DC-1695 Decal, Heater Plastic Control Box Deluxe D07-0009 Hose, 3/8" x 24" LG LP Gas 350 Max
HF-7318-1 Deluxe Circuit Board HH-7014 Jumper J6-2 Terminal Strip
FH-7049 Adapter, Connector PVC 3/8" Straight w/ Nut PNEG-588-04 Manual, Heater Deluxe Downwind 04
006-1354-7 Din Connector - 1/2" NPT 090-1705-4 Screw, MS #8-32 x 3/8" Phillips PHSEMS
HH-7046 Crimp, Disconnect 0.187" Female 007-1110-1 Nipple, 1" x 7"
