PNEG-1722 Series II Sweep Protected Cord Slip Ring Sump
3. Decals
The below
show the location of the decals and safety signs which should appear on the Series II
Sweep hopper with collector ring.
NOTE: Please remember safety signs provide important safety information for people working near
bin unloading equipment that is in operation. Any safety signs that are worn, missing, painted
over or otherwise illegible should be replaced immediately. Obtain FREE replacements by
contacting GSI.
HIGH VOLTAGE.
Will cause serious
injury or death.
Lockout power
before servicing.
DC-1224
DC-1224
On top of slip ring
shield plate
Location: Top of shield plate
and side of shield.
Size: 2-7/8" x 5"
Part #: DC-1224
