Top Dry Air Box Assembly
Topics Covered in this Chapter
▪ Assemble Air Box Covers
▪ Assemble Vent to Angle Plate
▪ Attach Vent Assembly to Side Plate
▪ Attach Side Plate Assembly to Support Frame
▪ Assemble Top Spout to Support Frame
▪ Install Inner Spout
▪ Assemble Door Frame
▪ Install Sliding Access Door
NOTICE
Use a silicone based caulk along all connecting surfaces throughout the assembly to
assure a water tight fit.
