Banks Power Ford Trucks: (Diesel ’94 - 97 7.3L Power Stroke) Power Systems- PowerPack, Stinger-Plus & Stinger '94-98 4

Bill of Materials
*Stinger systems 48401, 48403 and 48405 use tailpipe p/n 52129
*Stinger-Plus systems 48451, 48453 and 48455 use tailpipe p/n 52129
*PowerPack systems 48501, 48503 and 48404 use tailpipe p/n 52129
Item # Part # Description PowerPack Stinger-Plus Stinger
1-23 25970 BanKs teChni-Cooler sYstem 1 - -
1 25504 teChni-Cooler interCooler 1 - -
2 25511 InTERcooLER MoUnTInG BRAcKET, Lower Left 1 - -
3 25512 InTERcooLER MoUnTInG BRAcKET, Lower Right 1 - -
4 25515 InTERcooLER MoUnTInG BRAcKET, Upper Left 1 - -
5 25516 InTERcooLER MoUnTInG BRAcKET, Upper Right 1 - -
6 25530 TRAnSMISSIon-FLUID cooLER MoUnTInG BRcKT, Left 1 - -
7 25531 TRAnSMISSIon-FLUID cooLER MoUnTInG BRcKT, Right 1 - -
8 41304 interCooler inlet tuBe 1 - -
9 41308 interCooler outlet tuBe 1 - -
10 94285 SILIconE HoSE, 3 x 3” 2 - -
11 94510 SILIconE HUMP HoSE, 3 x 3” 2 - -
12 41312 twinram intaKe assemBlY 1 - -
13 41300 ComPressor outlet elBow 1 - -
14 93603 o-RInG, compressor outlet 1 - -
15 25510 air Dam 2 - -
16 25513 nUT PLATE ASSEMBLY, Left 1 - -
17 25514 nUT PLATE ASSEMBLY, Right 1 - -
18 62075 LooP cLAMP, 3 ⁄
4
x 5 ⁄
16
” 2 - -
19 92871 T-BoLT cLAMP, #313 with Liner 8 - -
20 25900 isolator stuD mount 2 - -
21 41360 SPAcER, 5 ⁄
8
”, Aluminum 2 - -
22 81100 SPAcER, Sway Bar 2 - -
23 91501 STUD, 5 ⁄
16
x 11 ⁄
8
” 2 - -
24-31 25970-5 fastener Kit 1 - -
24 91225 BoLT, 5 ⁄
16
” 18 x 3 ⁄
4
” Hex 4 - -
25 91228 BoLT, 5 ⁄
16
” 18 x 1” Hex 1 - -
26 91450 BoLT, 3 ⁄
8
” 16 x 3 1 ⁄
4
” Hex 4 - -
27 91117 BoLT, 1 ⁄
4
” 20 x 3 ⁄
4
” Hex 8 - -
28 91789 BoLT, 8mm 1.25 x 30mm Hex 2 - -
29 91831 BoLT, 10 32 x 1” Hex Washer Head 8 - -
30 25930 ISoLAToR BUSHInG, Rubber 2 - -
31 91210 nUT, 5 ⁄
16
” 18 nylock 5 - -
32-39 25970-5 fastener Kit 1 - -
32 91415 nUT, 3 ⁄
8
” 16 nylock 4 - -
33 91110 nUT, 1 ⁄
4
” 20 nylock 4 - -
34 91910 nUT, 10-32 nylock 8 - -
35 91803 LocKnUT, 8mm 1.25 Hex with Washer 2 - -
36 91202 WASHER, 5 ⁄
16
” sae 12 - -
37 91403 WASHER, 3 ⁄
8
” uss 8 - -
38 91102 WASHER, 1 ⁄
4
” sae 8 - -
39 91857 WASHER, #10 SAE 8 - -
90001 THREAD-LocKER, 6 ml 1 - -
40 41509 BanKs ram-air filter 1 1 1
90094 filter serViCe Kit 1 1 1
41 24450 QuiCK-turBo turBine housinG 1 1 -
42 93604 o-RInG, oil Feed 1 1 -
43 93605 o-RInG, oil Drain 1 1 -
44 52124 TURBInE oUTLET PIPE, Lower 1 1 1
45 52123 TURBInE oUTLET PIPE, Upper 1 1 1
46 52465 U-cLAMP, 3” 1 1 1
47 26001 HEATSHIELD BLAnKET, 6 x 14” 1 1 1
48 26013 WIRE TIE, Heatshield Blanket 4 4 4
49 52522 monster tailPiPe* 1 1 1
50 52467 U-cLAMP, 3 1 ⁄
2
” 2 2 2
51 64001 DYnafaCt PYrometer GauGe Kit 1 1 1
52 63025 DYnAFAcT BooST GAUGE, 30 PSI 1 1 1
53 63033 Boost GauGe installation Kit 1 1 1
54 63002 two-GauGe mountinG Panel 1 1 1
55 62001 cABLE TIE, 5” 4 4 4
56 62010 cABLE TIE, 8” 4 4 4
57 62801-62825 ottominD enGine CaliBration moDule 1 1 1
96322 owners manual 1 1 1
96392 ProDuCt reGistration CarD 1 1 1
96363 warrantY statement 1 1 1
96009 BAnKS PoWER DEcAL, Urocal 2 2 -
96004 BAnKS PoWER DEcAL, Large - - 2
96005 BAnKS PoWER DEcAL, Small - - 2
58 52513-52517 intermeDiate PiPe 1 1 1
59 52476 4” V-ClamP 1 1 1
60 53800 monster muffler 1 1 1
61 52383 5” Dual wall tiP 1 1 1
24
96493 v.4.0
