The same basic functions can also be accessed via the remote
control. Operation of the handset is the same regardless of
location – locally (source/IR emitter) or remotely (display/IR
receiver).
Simply toggle through the input sources connected to the matrix by
either pressing the left/right arrow buttons or buttons numbered
1 – 4 for each output.
IR Call-back of Matrix and Source Devices
The VPW-280755 is not only a switcher and extender of multiple
HDMI signals to multiple HDMI receivers located remotely, it
also passes IR control signals through the IR call-back system to
the matrix and HDMI sources for full, independent control of all
connected inputs from output locations using your remote handset.
www.vanco1.com
888.769.4156 7
BASIC OPERATION
Basic switching of various source inputs to output displays can be achieved via the front panel control of the
VPW-280755.
Outputs are numbered 1 – 4 with an input select button to the left. Repeated pressing of the select button of
a specific output scrolls through the HDMI input devices connected to the matrix, with the corresponding LEDs
illustrating when a device has been selected for that particular output. The chosen input will automatically
store for the output so, even when the matrix is powered off and on, on resumption the last selected input/
output combination will remain.
ATTENTION Users will notice a brief flicker on screen when switching between inputs/outputs – this is normal
for this model and represents the matrix resetting device HDCP settings to allow communication from a
different device.
For constant HDCP when switching with no noticeable screen resets, see Wyrestorm PRO, Pro Plus and
HDBaseT matrix ranges. See wyrestorm.com for more information
