The connection between 280759 Matrix and remote controller with RS-232 modem cable.

Pins definition of modem cable

280759

Remote Controller

PIN Definition

1 NC

2 Tx 2 Rx
3 Rx 3 Tx
4 NC

4 NC

5 GND

6 NC

7 NC

8 NC

9 NC

* RS-232 transmission format:
Baud Rate : 9600 bps
Data Bit : 8 bits
Parity : None
Stop Bit : 1 bit

OUTPUT

COMMAND

ACTION

Output 1

cir 00

Output 1 select Input1

cir 01

Output 1 select Input2

cir 02

Output 1 select Input3

cir 03

Output 1 select Input4

cir 04

Output 1 select Input5

cir 05

Output 1 select Input6

cir 06

Output 1 select Input7

cir 07

Output 1 select Input8

cir 08

Output 1 select Input previous

> cir 09

Output 1 select Input next

Output 2

cir 10

Output 2 select Input1

cir 11

Output 2 select Input2

cir 12

Output 2 select Input3

cir 13

Output 2 select Input4

cir 14

Output 2 select Input5

cir 15

Output 2 select Input6

cir 16

Output 2 select Input7

cir 17

Output 2 select Input8

cir 18

Output 2 select Input previous

> cir 19

Output 2 select Input next
