Velleman VCC6 User Manual

Page 4

VCC6/VCC7

22.07.2010

©Velleman nv

• supports remote surveillance and PTZ control through web browser, supports dynamic domain

name (DDNS)

• remote playback function

• configurable auto reboot, watchdog function and PC deadlock prevention

• auto mail notification: sends you a picture of the movement perceived by each camera

• mobile phone remote surveillance (Symbian, WinCE, Iphone, Android phone)

• manual only available in English !
VCC6 only
• max. display/recording rate of 25fps (PAL) / 30fps (NTSC)

• min. system requirements

o operating system: Windows 2000/XP/Vista/Win7/64-bit
o CPU: Intel Pentium III 800
o RAM: 256MB
o HDD: >250GB
o VGA: nVidia Geforce II MX320 32M

VCC7 only
• max. display/recording rate of 100fps (PAL) / 120fps (NTSC)

• min. system requirements

o operating system: Windows 2000(SP4)/XP(SP2)/Vista/Win7/64-bit
o CPU: Intel Pentium IV 2.8GHz
o RAM: 512MB
o HDD: >250GB
o VGA: nVidia Geforce IV MX440 64M

5. Overview

Refer to the illustration on page 2 of this manual.

Alarm port

Pin #

DB25F

Pin #

Definition

Function

1 25

5V Power

Source

(5V)

2 21

ALARM_COM Alarm

COM

3 23

ALARM_NC Alarm

Normal

4 1

ALARM_IN1

Alarm Input 1

5 22

ALARM_NO Alarm

Normal

Open

6 2

ALARM_IN2

Alarm Input 2

7 24

GND Ground

8 3

ALARM_IN3

Alarm Input 3

9 -

GND Ground

10 4

ALARM_IN4

Alarm Input 4

6. Hardware installation

• Verify whether your computer complies with the minimum system requirements. Install

Microsoft DirectX version 9.0 (or higher) before installing the DVR card

• Refer to the user manual of your computer for information on how to open the housing and

where the 32-bit PCI card slots are located. Make sure to switch off the computer and
disconnect it from the mains before opening the housing.

• Insert the DVR card into a free 32-bit PCI slot. Use an antistatic wrist strap.

• Install the cover with the DB25F connector next to the DVR card and connect the connector at

the end of the ribbon cable to the socket on the DVR card. This connector fits only one way,
do not force.

• When using an additional audio input device (not incl.), install it and connect it to the

motherboard when necessary. Refer to the user manual of the audio device.

• Close the housing of the computer.

• Do not connect the cameras yet.
